| Category |
Details |
| ENGINE |
| Make |
Ashok Leyland |
| Model |
ALU-W04D |
| Power |
76 HP @2200 rpm |
| Air Cleaner |
Combination of Dry & Water Cooled |
| Cooling System |
Water Cooled |
|
| CUTTING MECHANISM |
| Cutting Bar Working Width |
2285 mm |
| Cutting Height |
55-1250 mm |
|
| REEL |
| Type |
Tine Bar Pick up |
| Dia |
960 mm |
| Width |
2223 mm |
| Height Adjustment |
Hydraulic |
|
| FEEDER |
| Type |
Comb & Chain |
| Width |
777 mm |
|
| THRESHER DRUM |
| Dia (Including Spike) |
762 mm |
| Width |
508 mm |
| Speed |
750-850 RPM |
|
| CONCAVE |
| Width |
774 mm |
| Clearance |
Front 13-35 mm, Rear 9-12 mm |
| Adjustment |
Mechanical |
|
| CLEANING SIEVES |
| Length (Front/Rear) |
1219 mm / 457 mm |
| Width |
703 mm |
|
| CAPACITY |
| Fuel Tank |
150 Liters |
| Grain Tank |
700 Kg |
|
| TRACK ASSEMBLY |
| Size |
450x60x90x5F(BP) |
| Track Width |
1347 mm |
| Wheel Base |
1860 mm |
| Nos. of Rubber Grousers (Each Side) |
Five Nos. |
| Size of Rubber Grousers (Each Side) |
60 mm |
|
| TRANSMISSION |
| Type |
Hydrostatic |
| Pump |
Double Pump |
| Motor |
Double Pump |
|
| OVERALL DIMENSIONS |
| Length |
6450 mm |
| Width |
2620 mm |
| Height |
2880 mm |
| Weight |
4800 kg |
